PE Jaw Crusher

Purpose

The Jaw Crusher is mainly used for primary and secondary crushing all kinds of rocks with the hardness up to 320mpa, and also in the secondary crushing stages. The present jaw crusher is widely used in mines, smelting, building materials, highway, railroad, water conservancy and chemical industry and so on.
These crushers have many features, such as large crushing ratio, large capacity, homogeneous grain size, simple design, high reliability, simple repair, low cost, etc. It has been widely applied in the industries of mine, smelting, building materials, highway, railway, water conservancy, chemical industry, etc. Mobile Jaw Crusher available.

Learn more about Zhaoxi® Jaw Crusher

1. Large crushing ratio, homogeneous product grain size.
2. Free adjustment of output size, can meet different customers' requirements.
3. Reliable lubrication system, convenient to change the die.
4. Simple construction, high reliability, cheap operation expense.
5. Lower noise, less dust.

Working principle

The motor will connect with the belt wheel, drive the movable jaw by eccentric shaft. When the movable jaw goes up, the enclosed angle between the movable jaw and the spreading jaw increases, so the movable jaw gets closer to the fixed jaw, so the raw material is crushed and crushed. When the movable jaw descends, the movable jaw moves away from the fixed jaw, so the crushed raw material comes out. As the motor rotates continuously, the crusher cycles through the crushing and output of the raw material.
